Specifications
| Speaker type | - Floor standing, mini-monitor style with two enclosures and a three port, twin bass reflex loading. |
| Continuous power rating | - 75 Wrms system power |
| Frequency response | - 41Hz - 20kHz +/- 3db |
| Efficiency | - 95 db/w/m |
| Recommended amplifiers | - 3.5 - 75 Wrms into 8 ohms |
| Crossover frequency | - 5 kHz acoustic |
| Impedance | - 8 ohms nominal |
| Overall Dimensions | -
8 3/4"w x 11 1/8"d x 38 7/8"h - 22.3 cm w x 28.3 cm d x 98.3 cm h |
| Net weight | - approx 33lbs, 15kgs |
| Cabinet | -
Upper cabinet is made of ½"/ 12mm MDF with select panels damped
with a lead, rubberized bitumen laminate and acoustic foam. - Lower cabinet is made of 1"/ 25mm MDF with acoustic foam damping. |
| Crossover | - Audiophile, premium grade components and wiring tuned for a smooth frequency response with minimal off axis variation and low system distortions. |
| Woofer | - 6 ½" / 17cm driver extensively modified by fab audio. It has a uniquely damped steel basket, ultra light cone made from kenaf fibre paper, light foam surround, large 21oz/.6kg magnet and 1 3/8"/ 36 mm voice coil. A custom made ½" rubber gasket is used to isolate vibration between driver and cabinet. |
| Tweeter | - Precision manufactured ½" hyperdome tweeter with double magnet structure for high efficiency. |
